IPX10:4 DSP power amplifier, install
IPX10:4 DSP power amplifier, install
A 4-channel install DSP power amplifier rated 4 x 2500 W, with 96 kHz FIR Drive processing and OMNEO/Dante networking.
Put 2,500 watts on every channel and stop thinking about headroom. The IPX10:4 drives four channels of install audio with onboard DSP, so processing and amplification live in one rack space instead of two. Direct Drive runs 70V/100V lines straight off the amp — no bulky transformer, no insertion loss. Spec it, rack it, and trust the spec sheet to hold.
Key features
Headroom on every output
four channels at 2,500W each.
Amp and DSP in one box
onboard processing cuts the outboard rack.
Drive lines without a transformer
Direct Drive mode powers 70V/100V directly.
Built for the rack
Euroblock I/O, GPIO, and 32A mains for permanent installs.
Runs with the system
integrates into the Dynacord SONICUE control ecosystem.
Put it on the network
OMNEO/Dante audio, synchronized at 48/96 kHz, with FIR drive processing.
Short introduction
IPX Series Amplifiers
Complete the System
Where this unit fits, and what it pairs with.
Features
Networked install power with the processing on board. The IPX10:4 drives 4 channels at up to 2500 W each, with a native 96 kHz DSP, FIR Drive up to 1025 taps, and Dante/OCA over OMNEO with fallback for redundancy. Class D output and ecoRAIL keep efficiency high and running costs down, while load monitoring and pilot-tone supervision watch every line. Two rack units. Stadiums, houses of worship, retail, transport hubs, and multi-zone installs that route and process from the amplifier itself.
- Multichannel power: 4 channels 2500 W/4 Ohms, 70 V, 100 V, or 3000W/2.6 Ohms.
- Processing built in: native 96 kHz DSP with FIR Drive up to 1025 taps.
- Networked audio: Dante / OCA over OMNEO with fallback for redundant routing.
- Watches the system: load monitoring and pilot-tone supervision on every line.
- Efficient by design: Class D output with ecoRAIL power management to cut running cost.
- ghostPOWER keeps DSP and network running to bridged mainspower switching in mission critical systems
Specifications
Overview & Features
- Configuration
4-channel
Acoustic Performance
- Frequency Response
20 Hz to 20 kHz (±0.5 dB)
- THD+N
< 0.05 %
- Crosstalk between channels (dBA)
< -80 dB
Power & Amplification
- Total Output Power*
10.000 W
- Bridged Output Power 4 Ω
5200 W
