ELX200-12SP
ELX200-12SP
A 12-inch powered subwoofer with 1,200 W of Class-D punch and DSP you tune from your phone.
Features
Set the bottom and walk away. The ELX200-12SP drives a custom EVS-12L 12-inch woofer with up to 1,200 W of Class-D power and built-in QuickSmartDSP, reaching up to 129 dB max SPL. Pick Music, Live, or Club, dial the sub/top crossover, and save five of your own presets. QuickSmart Mobile over Bluetooth LE lets you monitor and adjust up to six speakers from out front — where the mix actually matters. Mobile rig, club install, corporate room.
- Power that carries — up to 1,200 W Class-D drives the EVS-12L to a max 129 dB SPL.
- Tune from the floor — QuickSmart Mobile over Bluetooth LE controls up to six speakers from out front.
- Dial it in fast — Music, Live, and Club presets, sub/top crossovers, three-band EQ, five user presets.
- Set it and trust it — onboard limiter monitoring keeps the system safe when it's pushed.
- Lift it solo — integrated M20 pole-mount plate and two-handle design, in a compact 15 mm wood box.
Specifications
Transducers & Drivers
- Element Type
EVS-12L 300 mm (12 in)
Power & Amplification
- Powered
true
- Power Handling
1200 W
- Power consumption (W)
100 - 240 V~, 50 - 60 Hz, 1.2 0.6 A
Connectivity & I/O
- Connectivity
(2) XLR/TRS combo jacks and (2) XLR link outputs
Construction & Materials
- Enclosure
15 mm plywood with EVCoat
