EVID-C4.2-G2 Ceiling speaker 4" 70/100V white
EVID-C4.2-G2 Ceiling speaker 4" 70/100V white
A 4-inch coaxial ceiling speaker that mounts fast and reads clean in any room.
Put even, natural sound overhead and keep the ceiling looking clean. The EVID-C4.2-G2 coaxial driver throws a true point source, so coverage stays uniform as people move through the space. SwiftLock mounting drops it in fast and holds it safe, and front-panel taps set 70V or 100V power without pulling the speaker back down. Retail floor, lobby, restaurant — background that's there when you want it and never in the way.
Key features
In fast, in safe
SwiftLock mounting installs quickly without sacrificing security.
Even coverage
4" coaxial point-source design keeps response smooth off-axis.
Set power at the baffle
front-switchable 70V/100V taps (1.9–30W) or 8-ohm bypass.
Reads clean
semi-gloss white grille and low-profile body fit tight ceilings.
Part of a system
pairs with the wider EVID ceiling, surface, and in-wall range.
Pass inspection
UL 1480A, UL 2043 air-handling, and CSA C22.2 No. 205 certified, packaged in pairs.
Explore the Full EVID-C-G2 Range
Every EVID ceiling format — premium C-G2, essential EC, and all-in-one PC systems — compared side by side on the Ceiling Speakers page.
Features
Put even, natural sound overhead and keep the ceiling looking clean. The EVID-C4.2-G2 coaxial driver throws a true point source, so coverage stays uniform as people move through the space. SwiftLock mounting drops it in fast and holds it safe, and front-panel taps set 70V or 100V power without pulling the speaker back down. Retail floor, lobby, restaurant — background that's there when you want it and never in the way.
- In fast, in safe — SwiftLock mounting installs quickly without sacrificing security.
- Even coverage — 4" coaxial point-source design keeps response smooth off-axis.
- Set power at the baffle — front-switchable 70V/100V taps (1.9–30W) or 8-ohm bypass.
- Reads clean — semi-gloss white grille and low-profile body fit tight ceilings.
- Part of a system — pairs with the wider EVID ceiling, surface, and in-wall range.
Specifications
Acoustic Performance
- Max SPL
106
- Frequency Range (-10 dB)
70 Hz – 20,000 Hz
- Coverage Angle (cone)
130
- Sensitivity (1W/1m)
88 dB SPL 1 W, 1 m
Transducers & Drivers
- LF transducer size (in)
4 in
- HF transducer size (in)
19 mm [0.75in]
